1.Compact design and auto tube feed. Driving part fully-closed.
2.Tube washing and feeding marking identification, filling, folding, sealing, code printing and finished product output all conducted by a fully auto control system.
3.Tube washing and feeding conducted pneumatically, accurate and reliable.
4.Auto picketage affected by photoelectric inductance.
5.Easy adjustment and dismantling
6.With easy and quick adjustment, it is suitable for using multiple kinds of soft tubes for filling.
7.The part contacting materials is made of 316L stainless steel, clean, sanitary and conforming to CMP for medicine manufacture.
8.With safety device, the machine is shut down when the door is opened and filling carried out only with tubes fed. Overload protection provided.
Application:
The automatic aluminum tube filling machine is suitable for ointment, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste and other liquid or paste materials. The outrigger mechanism of the machine is made of aluminum alloy and stainless steel.
Optional Supporting Devices: three-dimensional packaging machine, cartoning machine, sealing and cutting machine, heat shrinking machine, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Examples:
Model | LFF-ZWS-008 | |||
| Tube material | Aluminum / Metal tube | |||
| Tube diameter | φ15—φ70 | |||
| Tube length | 50—180（customizable） | |||
Filling volume | 40—60ml/pcs（adjustable） | |||
| Filling accuracy | ≤±1% | |||
Product capacity | 3600—43600 pcs/h（adjustable） | |||
Working pressure | 0.55—0.65Mpa | |||
Motor power | 2KW (380V/220V 50Hz/60Hz, three phase) | |||
| Working Position | 10Automatic Aluminum Tube Filling And Sealing Machine with Cover Pcs | |||
