Application:
Suitable for automatic packing of grain and solid food, such as dry tomatoes, dry fruits, nuts, beans, candy, cereal, chocolate, biscuits, peanuts, capsules, seeds, etc. Different kinds of products with stand-up pouches, doypack with zippers, 3-side seal bags, 4-side seal bags, flat bags, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Wide Applications: Handles various states and types of solids, including granules.
2. Versatile Pouch Range: Accommodates all types of pre-made pouches.
3. Easy Operation: PLC controller and HMI system simplify operation.
4. Quick Adjustment: Changes between different pouches in under 10 minutes.
5. High Automation: Unattended weighing and packing with automatic machine alarms for failures.
6. Effective Prevention System: No filling or sealing if the bag is not properly opened, reducing waste and saving costs.
7. Sanitary Construction: Product contact parts made of SUS304, meeting GMP standards for safety and hygiene.
8. Maintenance-Free Bearings: Imported engineer plastic bearings require no lubrication and prevent contamination.
9. Efficient Vacuum Generator: Low consumption, high efficiency, and long lifespan.
10. Pre-Made Bag Packing: Ensures excellent sealing quality, enhancing the final product.
| Model | LD-8200 | LD-8300 |
| Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc | |
| Size | W: 70-200 | W: 200-300 |
| Filling range | 10-1000g | 10-2500g |
| Packing speed | 40-60 bags/min (speed is determined by the product filling quantity) 25-40 bags/min (for zipper pouch) | 30-40 bags/min (speed is determined by the product filling quantity) 25-35 bags/min (for zipper pouch |
| Average precision | ≤ ±1% | |
| Total power | 2.5KW | 4KW |
| Dimensions | 1900mm*1570mm*1700mm（L*W*H） | 2450mm*1750mm*1450mm（L*W*H） |
| Workflow | 1. Giving bag, 2. Coding date(option), 3. Open zipper, 4. Open the top and bottom, 5. Filling, vibrating (option), 6. The filling product is integrated by vibration, 7. Exhaust(option), closing zipper, sealing, 8. Forming and output | |
After receiving your inquiry,We will send you the quotation as soon as possible.
