Application:
It suitable for automatic packing for grain, such as fertilizer, silica gel, beef jerky, fastener, bolt, candy, nuts, dry fruits, beans, nuts, candy, cereal, chocolate, biscuit, peanut, seeds, chemicals, sugar, etc. Different kinds of product with stand up pouches, doypack with zipper, 3 side seal bags, 4 side seal bags, flat bags, pouch with hole, spout pouch, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
Simple structure, easy to maintain and install;
Many world famous brand parts;
Automatic and intelligent operation;
Less waste of bags and materials;
Contact material: 304 stainless steel;
Waterproof system, easy to clean;
Perfect sealing, improve product grade.
Work Process:
| Model | LD-8200 |
| No.of working stations | Eight |
| Bags size | W：100-200mm L: 100-400mm |
| Filling range | 10-2500g depending on type of products |
| Packing speed | 25-60bag/min（speed is determined by the product filling quantity） |
| Total power | 2.5KW |
| Weight | 1400kgs |
| Dimensions | 1140mm X 1500mm X 1560mm（L*W*H） |
| Work flow | giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product |
| Main standard parts | 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system |
After receiving your inquiry,We will send you the quotation as soon as possible.
