Application:
Packaging various kinds of regular objects like Candy, chocolate, chewing gum and suit for square, spherical, disc, cylindrical, kinked, oval and all kinds of special-shaped candies and solid blocks.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
servo motor control, Bag length can be set and cut in one step,saving time and film.
Interface features easy and quick setting and operation
Self failure diagnosis, clear failure display
High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
Temperature independent PID control, more suitable for packaging different materials
Positioned stop function, without sticking knife or wasting film.
Simple driving system, reliable working, convenient maintenance.
All control is realized through software,easy for function adjusting and technical upgrade.
| Type | LP-250C |
| Film width | 50-120mm |
| Bag length | 10-50mm |
| Bag width | 10-30mm |
| Product height | 4-25mm |
| Film roll diameter | 320mm |
| Packaging rate | 50-900 bags/min |
| Power | 380v,50/60 Hz ,3.2kw, |
| Machine size | 3850x1100x1800mm |
| Machine quality | 720kg |
| Film material | OPP、PE、PVC、OPP/CPP、PT/PE、KOP/CPP Aluminum Coating Film/ Aluminum Film |
After receiving your inquiry,We will send you the quotation as soon as possible.
