Application:
This machine is suitable for packaging medicine, cosmetics, food, and chemical products, including fruit juice, beverages, medicinal liquids, health care liquids, olive oil, ketchup, sauces, seasonings, flavorings, pastes, shampoos, creams, and body wash liquids. It ensures efficient and reliable packaging for various liquid and viscous products.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Integrated Metering and Packaging System: Combines a horizontal bag-feeding packaging machine with a cylinder pump blanking system for seamless operation.
2. User-Friendly Bag Slot: Designed for easy bag placement, featuring an automatic bag-pressing device to enhance efficiency.
3. Smart Sensing for Efficiency: Equipped with an imported pressure sensing device to prevent blanking and unsealing when no bag is detected, saving packaging materials.
4. Advanced Touchscreen Control: Includes a color touch screen with a multifunctional design for simple and intuitive operation.
5. Durable and Corrosion-Resistant Design: Made with 304L stainless steel for the exterior, with carbon steel frame parts treated for acid, salt, and corrosion resistance.
6. High-Quality Material Selection: Accessories are mold-produced with primary materials including 304 stainless steel and alumina for reliability and durability.
7. Optional Customization: Offers additional systems for coding, printing, exhaust, and punching to meet diverse packaging needs.
| Type | LDSP-140 | LDSP-160/LDSP-210 | LDSP-260 |
| Bag Type | 3-side, 4-side sealing bag, stand-up bag, handbag, spout bag, zipper bag, compound bag, etc. | ||
| Bag Size | 110-230mm*80-160mm(L*W) | 110-230mm*80-160mm（L*W） 110-320mm*100-210mm（L*W） | 160-380mm/140-260mm（L*W） |
| Filling Range | 20g-500g | 20g-1kg | 20g-1kg |
| Packing Speed | 20-45bags/min(speed is determined by the product filling quantity) | 20-50bags/min (speed is determined by the product filling quantity) | 20-40bags/min (speed is determined by the product filling quantity) |
| Machine weight | 800KG | 900KG | 900KG |
| Total Power | 2.5KW | ||
| Work Flow | 1. Giving bag, 2. Pick up the bag(coding), 3. Open the bag up and down, 4. Filling, 5. Heating sealing, 6. Output of product | ||
| Dimensions | 1750*1285*1360mm(L*W*H) | 2140*1366*1360mm(L*W*H) | 2140*1366*1360mm(L*W*H) |
| Collocation | Screw metering, screw elevator | ||
After receiving your inquiry,We will send you the quotation as soon as possible.
