Application:
The machine can pack ice pop, water, oil, fruit juice, milk, wisky, soybean milk.Liquid chocolate liquid, oral liquid, garlic paste and shampoo and so on
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
1. Using PLC control, with automatic photoelectric tracking and correction function;
2. The bag length can be adjusted randomly for convenience;
3. When the machine fails, it will be automatically displayed on the operation interface, which is convenient for maintenance;
4. When the temperature exceeds the limit, it will stop automatically to ensure the quality of the finished product;
5. It complies with GMP industry standards, and has the characteristics of stable performance, convenient operation and maintenance, and efficiency;
6. Different filling structures can be configured to realize different packaging of powders, liquids, granules and sauces.
| Type | LD-DL-024 |
| Bag length | 30--140mm(L) |
| Bag width | 10---60mm(W) |
| Max width of roll film | 450mm |
| Packing speed | 30—55 bag /min / lane |
| Air consumption | 0.65mpa |
| Gas consumption | 0.3m3/min |
| Power voltage | 380VAC/220VAC/50Hz |
| Power | 2.6 KW |
| Dimension | 1000mm(L)*1000mm(W) *2000mm (H) |
| Weight | 430 kg |
After receiving your inquiry,We will send you the quotation as soon as possible.
