Application:
This liquid premade pouch packing machine is suitable for all kinds of liquid products and can pack different premade bags. It is applied for filling various kinds of liquids such as laundry liquid, honey, milk, oil, ketchup, paste, sauce, fruit juice, chili sauce, sunflower oil, tomato sauce, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Adopted PLC simens brand intelligent design easy operate.
2. Speed 15-30 bags per minute can meet end customers' start and middle-class requirements.
3. Gear pump for measuring contact part SS316.
4. Full frame SS304 high hygiene easy clean.
5. Filling nozzle with anti-leak design.
6. Double sealing way for sealing tightly.
Workflow:
1. Bag giving
2. Open bag
3. Gear pump for measuring the filling range
4. Filling nozzle with anti-leak design
5. Double sealing
6. Stampe code
7. Finished bag output
Model | LDSP-160L |
Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc |
size | W: 100-210 mm |
Filling range | 10-1000g |
Packing speed | 10-45 bags/min (speed is determined by the product filling quantity) |
Average precision | ≤ ±1% |
Total power | 2.5KW |
Weight | 900 KG |
Main standard parts | 1. Code printer 2. PLC control system 3. Bag opening device 4. Vibration device 5. Cylinder 6. Electromagnetic valve 7. Temperature controller 8. Vacuum pump 9. Inverter 10. Output system |
After receiving your inquiry,We will send you the quotation as soon as possible.
