Application:
The conversion screw can measure different weights and precisions, and is suitable for a variety of powdered materials such as:milk powder, protein powder, Chinese medicine powder, health products, chicken powder Automatic filling of powder products such as condiments and snack foods.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
1. The use of card disk positioning mechanism, Chinese and English LCD touch screen, PLC control system, work at a glance.
2. The use of cans or bottles of containers, no bottles and bottles are not filling, can be configured automatically into the bottle into the tank system.
3. The structure of the whole machine, reasonable layout, change packaging varieties, cleaning and convenience.
4. Imported servo motor, high speed, large torque, which greatly improves the accuracy of packaging.
Model | LF-PJ-02 |
Filling Range | 5-1000g |
Packing Accuracy | ±1% |
Filling Speed | 0-40 cans/min |
Bottle Diameter | 30-100mm, 100-200mm |
Bottle Height | 50-350mm |
Hopper Capacity | 50L |
Voltage | 380V220V 60HZ |
Power | 2000W |
Weight | 500kg |
Size | 2000*1150*2300mm |
After receiving your inquiry,We will send you the quotation as soon as possible.
