Application:
Suitable for packing all kinds of liquid material such as paste, jam, mayonnaise, liquid milk, water, honey, juice, tomato paste, ketchup, sauce, oil, etc.
Kindly Reminder:
Please tell us the following information when you send us an inquiry. Based on your message, we will suggest the optimum solution to you for reference. Thank you.
1. Your product
2. Bags/sachets/foil bag weight
3. Bags/sachets/foil bag dimension
4. Bags/sachets/foil bag material
Packing Exambers:
1. Computer PLC control and automatic alarming function.
2. The body is mainly made of high-quality stainless steel, beautiful appearance that is clean and sanitary, and completely meets the food hygiene requirements.
3. Servo control, and precise cutting, to ensure perfect packaging effect.
4. Accurate measurement, high packaging efficiency, compact structure, low noise, and long service life.
5. Weight measuring, bag making, filling, sealing, cutting, and bag counting can be done automatically.
6. Bag type can be customized to 3 or 4 sides sealing bag, pillow bag, long stick bag, link bag, etc.
Model | LD-320L | LD-380L |
Film width | 120-320mm | 180-380mm |
Bag length | 50-200mm | 60-280mm |
Bag width | 50-150mm | 60-180mm |
Diameter of film roll | Max.300mm | Max.320mm |
Packing speed | 35-70bag/min | |
Measuring range | 50-500ml | 50-750ml |
Film thickness | 0.04-0.07mm | |
Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
Machine weight | About 300kg | About 450kg |
After receiving your inquiry,We will send you the quotation as soon as possible.
