Application:
Suitable for all kinds of liquid, viscous bodies and pastes.Such as Ice Lolly, olive oil, soy sauce, juice, honey, jam, mayonnaise, ketchup; shampoo, conditioner, hand soap, hand-washing gel, toner, lotion, makeup remover.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
Simple structure in linear type ,easy in installation and maintation.
Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
High pressure double crank to control the die opening and closing.
Running in a high automatization and intellectualization,no pollution
Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Model | LD-280BKL | LD-520BKL |
| Track number | 4~6Land | 8~12Land |
Roll film width | 420mm | 520mm |
Bag width | 17-30mm | 17-30mm |
Bag length | 50-180mm | 50-180mm |
| Film W&D | Max.280mm,0.07-0.1mm | Max.560mm, 0.07-0.1mm |
| Sealing type | Backsealing/ Stick bag | |
Speed | 5-35bags/min/lane | 5-35bags/min/lane |
Power | 2.2kw/50/60Hz | 3kw/50/60Hz |
Weight | 600kg | 700kg |
After receiving your inquiry,We will send you the quotation as soon as possible.
