Application:
Automatic Bottles Weighing Filling Machine, it is suitable for sugar, salt, roasted peanut, food, oatmeal, seeds, rice, sesame, gourmet powder, chicken powder and other even powder.
Filling containers: bottles; plastic cans; glass cans; tinplate cans; cartons, etc.
Optional supporting devices: Multihead weigher; combination scale; Z-type lifting feeder; bottle unscrambler; capping machine; labeling machine; aluminum foil sealing machine, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1.The machine can weight multi-materials at the same time.
2.Based on producing status,can change parameter during production running.
3.Modularization design,replaceable Aluminum box,easy operation.
4.Card insertion drive panel,easy to maintain,low cost.
5.The design of operation panel is reasonable and simple, which faciliates adjustment and maintenance.
6.It has high production capacity and degree of automation which may save labor cost. It is applicable as equipment of sealing and filling production line.
Model | LF-GA-001 |
Filling diameter | 40-130mm |
Height | 50-200mm |
Speed | 15-25cans per minute |
Material | Stainless steel 304 |
Control interface | LCD display |
Origin | 0.6-0.8Mpa |
Power | 3.8kw |
Voltage | 220V, 50 / 60Hz |
Weight | 250kg |
Size | 2000 * 1000 * 2000mm |
After receiving your inquiry,We will send you the quotation as soon as possible.
