Application:
Suitable for various granule materials in premade pouch style, such as beans, nuts, dry fruits, candy, cereal, chocolate, biscuits, peanuts, capsules, seeds, chemicals, sugar, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
1. The machine incorporates an advanced PLC system from Japan's Mitsubishi, paired with a user-friendly touchscreen interface.
2. The machine detects pouch-related errors, such as pouch open issues, insufficient filling, or incomplete sealing.
3. In case of abnormal air pressure or heater disconnection, the machine stops automatically.
4. An electrical motor allows easy adjustment of bag width.
5. When the door is opened, the machine stops working, ensuring operator safety and preventing dust contamination.
6. Using preformed bags, the machine achieves minimal material wastage.
7. Different feeders can be used for solid, liquid, thick liquid, powder, and other materials.
8. Whether multi-layer compound bags or monolayer PE/PP bags, the machine handles preformed bags made from film or paper.
Model | LDB-200 | LDB-300 | LDB-430 |
Pouch Type | Four-side Sealed Bags, stand-up pouches, zipper bags, three-side sealed bags, paper bags, etc. | ||
Capacity | 0-60 bags/min | 0-15 bags/min | |
Bag Size | W: 70-150 mm; L: 70-150 mm | W: 80-300 mm; L: 100-300 mm | W: 80-300 mm; L: 100-430 mm |
Sealing Type | Straight grain, the pitch is 1 mm (optional reticulate) | ||
| Sealing Width | 10 mm(5-20 mm) can be customized | ||
| Voltage | 220V, 50/60HZ, 1.2KW | ||
| Air Pressure | 0.65 Mpa | ||
| Air Consumption | 0.3 m³/min | ||
| Dimension | 1770*600*1230 mm (L*W*H) | 1770*600*1360 mm (L*W*H) | |
After receiving your inquiry,We will send you the quotation as soon as possible.
